Force range: 500LBS(2KN) to 12825LBS(57KN)
Max riveting capacity: M10 nut M8 stud M6 standoff carbon steel
Throat depth: 450mm
Throat height: 400mm
Stroke: 200mm
Main power: 1.5KW
Current: 4A
Hydraulic oil: 46#/32#
Oil tank reservoir: 60L
Air pressure: 0.4-0.6Mpa
Power supply: 380V 3 phase 5 core 50-60Hz
Package size (WDH): 41″x47″x86″ (1050x1200x2200mm)
Weight: 650KG (1433LBS)
